24V, 10A spring clamp terminals
|Input||AC 100 - 240V (-15%/+10%)|
|DC 110V - 150V (± 20%)|
|Dimensions (WxHxD)||39 x 124 x 117mm|
|AC Input voltage||AC 100 - 240V (-15%/+10%)|
|DC Input voltage||DC 110V - 150V (± 20%)|
|Input inrush current limitation||active|
|Input inrush current||6A / 9A|
|External input fuse recommendation||B-6A / C-6A|
|Output current range||10A|
|Output current||10A at 24V|
|Power reserves||20% Power Boost|
|Derating||6W/°C for >+60°C|
|Ripple and noise voltage max.||50mVpp|
|Dimensions (WxHxD)||39mm x 124mm x 117mm|
|Weight per unit (excl. packaging)||600g|
|Mounting method||DIN rail|
|Operating temp. range||-25°C to 70°C|
|Connection method||Spring clamps|
|Power losses, typ.||13.4W|
|MTBF SN 29500 @ 40°C (h)||641000h|
