SLD2.100

DC/DC converter
5V, 8A
Datasheet
DC output 5 - 5.5Vdc
8A
40W
Input DC 24V (-25%/+50%)
Dimensions (WxHxD) 49 x 124 x 102mm
Weight 470g
Compare
Product status: Stock item

Please note that this product is not for new designs. Please have a look at the alternative products.

Input data

DC Input voltage DC 24V (-25%/+50%)

Output data

Nominal voltage 5Vdc
Adjustment range 5 - 5.5V
Output current range 8A
Output current 5.5V
8A at 5V
Output power 40W
Derating 1.5W/°C for >+60°C
Ripple and noise voltage max. 50mVpp

Overview

Dimensions (WxHxD) 49mm x 124mm x 102mm
Weight per piece (excl. packaging) 470g
Operating temp. range 0°C to 40°C
Mounting method DIN rail
Efficiency, typ. 82%
Power losses, typ. 8.5W
MTBF SN 29500 @ 40°C (h) 510000h
Connection method Screw terminals
