CPS20.241-60
DC/DC converter
24.5 V, 16.3 A railway applications
Datasheet
24.5 V, 16.3 A railway applications
| DC output | 24.5 Vdc |
|---|---|
| 16.3 A | |
| 400 W | |
| Input | DC 110 V (-30 %/+40 %) |
| Dimensions (WxHxD) | 65 x 124 x 127 mm |
| Weight | 980 g |
Input data
| DC Input voltage | DC 110 V (-30 %/+40 %) |
|---|
Output data
| Nominal voltage | 24.5 Vdc |
|---|---|
| Adjustment range | 24.5 V |
| Output current range | 16.3 A |
| Output current | 16.3 A at 24.5 V |
| Output power | 400 W |
| Ripple and noise voltage max. | 70 mVpp |
Overview
| Dimensions (WxHxD) | 65 mm x 124 mm x 127 mm |
|---|---|
| Weight per unit (excl. packaging) | 980 g |
| Mounting method | DIN rail |
| Operating temp. range | -40 °C to 70 °C |
| Connection method | Spring clamps |
| Efficiency, typ. | 93.7 % |
| Power losses, typ. | 26.9 W |
| MTBF SN 29500 @ 40 °C (h) | 571000 h |
