|DC output||24 - 28Vdc|
|10 - 8.6A|
|Input||DC 24V (-25%/+46%)|
|Dimensions (WxHxD)||42 x 124 x 117mm|
|DC Input voltage||DC 24V (-25%/+46%)|
|Adjustment range||24 - 28V|
|Output current range||10 - 8.6A|
|Output current||8.6A at 28V|
|10A at 24V|
|Power reserves||20% Power Boost|
|Ripple and noise voltage max.||50mVpp|
|Dimensions (WxHxD)||42mm x 124mm x 117mm|
|Weight per unit (excl. packaging)||500g|
|Mounting method||DIN rail|
|Operating temp. range||-25°C to 70°C|
|Connection method||Screw terminals|
|Power losses, typ.||14.8W 14.8W|
|MTBF SN 29500 @ 40°C (h)||731000h|
