UZO24.121

Battery module without battery
24 V same as UZK24.121, batteries not included

Dimensions (WxHxD)	203 x 186 x 124 mm
Weight	800 g

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Technical data

Overview

Dimensions (WxHxD)	203 mm x 186 mm x 124 mm
Weight per unit (excl. packaging)	800 g

Techn. documentation

Datasheet

(641 KB)

Installation manual

(158 KB)

Installation manual - CCC - CN

(268 KB)

2-D dimensional mechanical CAD drawing DXF

(781 KB)

2-D dimensional mechanical drawing DWG

(175 KB)

3-D dimensional mechanical CAD model STEP

(361 KB)

3-D dimensional mechanical model DWF

(313 KB)

Image UZO24.121

(215 KB)

Approvals / Product Compliance

EU Declaration of Conformity

(40 KB)

IEC 61010-2-201 CB Scheme

(99 KB)

UL 61010-2-201 Canada

UL 61010-2-201 USA

ATEX EN 60079

(2 MB)

IECEx IEC 60079

(3 MB)

Class I Div. 2 Canada - CSA

(171 KB)

Class I Div. 2 USA - CSA

(171 KB)

Material Compliance Declaration – RoHS, REACH, ...

(155 KB)

PULS Conflict Minerals Statement & RMI Reporting Templates (CMRT/EMRT)

(3 MB)

Features

24 V, 12 Ah Battery capacity (2x 12 V batteries in series)
Small mounting footprint
2 m power leads included
Includes a PT1000 temperature sensor
Includes an auto-resettable fuse for the center-tap connection
3 year warranty, except for batteries, which are considered a service part

Commercial info

Article number	UZO24.121
Product status	Lead time on request
UPC code	875404002079
Warranty period (months)	36
Country of origin	Czech Republic
Packaging unit	1 PU pc
Weight per piece (excl. packaging)	800 g
E classification	eClass 5.1 27040603
	eClass 6.x 27040603
	eClass 7.x 27049201
	eClass 8.0 27049201
	eClass 9.0 27049201
	ETIM 4.0 EC000357
	ETIM 5.0 EC000357
Customs tariff number	85044083
