PISA-M-408
Neu
Elektronischer Schutzschalter
24 V, 20 A 4 output channels: Output: 4x 8 A max.20 A
Datenblatt
24 V, 20 A 4 output channels: Output: 4x 8 A max.20 A
| DC Ausgang | DC 24 V |
|---|---|
| Eingang | DC 19.2 V - 30 V |
| Abmessungen (BxHxT) | 22.5 x 104 x 98 mm |
| Gewicht | 100 g |
Eingangsdaten
| DC-Eingangsspannung | DC 19.2 V - 30 V |
|---|---|
| DC Ruhestrom, typ. | 30 mA |
| Erforderliche Eingangsspannung zum Einschalten der Ausgänge, typ. | 9.6 Vdc |
Ausgangsdaten
| Ausgangsstrom (Summe aller Ausgänge) | 20 A |
|---|---|
| Einschaltverzögerung der Ausgänge | 350 ms |
Überblick
| Abmessungen (BxHxT) | 22.5 mm x 104 mm x 98 mm |
|---|---|
| Weight per unit (excl. packaging) | 100 g |
| Montageart | DIN-Schiene |
| Housing material | Kunststoff |
| Arbeitstemperaturbereich | -25 °C bis 70 °C |
| Anschlussklemmen | Push-in terminals |
| Verlustleistung, typ. | 3,5 W |
| Verlustleistung Leerlauf, typ. | 0,7 W |
| MTBF SN 29500 @ 40 °C (h) | 1142000 h |
