CP20.248
Hutschienen-Netzteile für 1-Phasen-Systeme
24 V, 20 A Monitoring-Display
Datenblatt
24 V, 20 A Monitoring-Display
| DC Ausgang | 24 - 28 Vdc |
|---|---|
| 20 - 17.1 A | |
| 480 W | |
| Eingang | AC 100 - 240 V (-15 %/+10 %) |
| DC 110 V - 300 V (± 20 %) | |
| Abmessungen (BxHxT) | 48 x 124 x 127 mm |
| Gewicht | 835 g |
Eingangsdaten
| AC-Eingangsspannung | AC 100 - 240 V (-15 %/+10 %) |
|---|---|
| DC-Eingangsspannung | DC 110 V - 300 V (± 20 %) |
| Oberwellenkorrektur | aktiv |
| Leistungsfaktor | 0.99 |
| Leistungsfaktor | 0.980000 |
| Einschaltstrombegrenzung | aktiv |
| Einschaltstrom (Spitze) | 4.5 A |
| Externe Eingangsabsicherung min. | B-10 A / C-10 A |
Ausgangsdaten
| Nennspannung | 24 Vdc |
|---|---|
| Einstellbereich | 24 - 28 V |
| Ausgangsstrombereich | 20 - 17.1 A |
| Ausgangsstrom | 17.1 A bei 28 V |
| 20 A bei 24 V | |
| Ausgangsleistung | 480 W |
| Leistungsreserve | 20 % Power Boost |
| Derating | 12.5 W/°C für >60 °C |
| max. Restwelligkeit | 50 mVpp |
Überblick
| Abmessungen (BxHxT) | 48 mm x 124 mm x 127 mm |
|---|---|
| Weight per unit (excl. packaging) | 835 g |
| Montageart | DIN-Schiene |
| Housing material | Metal |
| Arbeitstemperaturbereich | -25 °C bis 70 °C |
| Anschlussklemmen | Schraubklemmen |
| Wirkungsgrad, typ. | 95.6 % |
| Verlustleistung, typ. | 29.6 W , 22.1 W |
| MTBF SN 29500 @ 40 °C (h) | 463000 h |
| DC-OK signal | ja |
