UBC10.241

DC-USV mit integrierter Batterie
24V, 10A
battery included
Datenblatt
DC Ausgang DC 24V
10A
Eingang DC 24V
Abmessungen (BxHxT) 123 x 124 x 119mm
Gewicht 2850g
Preis
306,72 €
zzgl. gesetzl. MwSt., versandkostenfrei
Vergleichen
Produkt Status: Online verfügbar (26 Stück)
Lieferung: 1 - 4 Werktage

Eingangsdaten

DC-Eingangsspannung DC 24V
Eingangsstromverbrauch (inkl. Ladestrom) 1.3A

Ausgangsdaten

Nennspannung 24Vdc
22.5Vds
Ausgangsstrom 15A
10A

Puffer

Speichermedium Built-in lead acid battery
Erlaubte Batteriegröße 12V, 5Ah
Temperaturnachführung der Ladeschlussspannung automatically with temp. sensor

Überblick

Abmessungen (BxHxT) 123mm x 124mm x 119mm
Gewicht pro Stück (ohne Verpackung) 2850g
Arbeitstemperaturbereich 0°C bis 40°C
Montageart DIN-Schiene
MTBF SN 29500 @ 40°C (h) 886000h
Anschlussklemmen Käfigzugfederklemmen
