UF20.241

Puffermodul
24V, 20A
electrolytic capacitor buffer module typ. 310ms at 20A
Datenblatt
DC Ausgang DC 24V
20A
Eingang DC 24V - 24V (-7%/+20%)
Abmessungen (BxHxT) 64 x 124 x 102mm
Gewicht 740g
Preis
211,56 €
zzgl. gesetzl. MwSt., versandkostenfrei
Vergleichen
Produkt Status: Online verfügbar (26 Stück)
Lieferung: 1 - 4 Werktage

Eingangsdaten

DC-Eingangsspannung DC 24V - 24V (-7%/+20%)

Ausgangsdaten

Nennspannung 24Vdc
22.5Vds
Ausgangsstrom 24A
20A

Puffer

Speichermedium Elektrolytkondensatoren

Überblick

Abmessungen (BxHxT) 64mm x 124mm x 102mm
Gewicht pro Stück (ohne Verpackung) 740g
Arbeitstemperaturbereich -25°C bis 70°C
Montageart DIN-Schiene
MTBF SN 29500 @ 40°C (h) 2327000h
Anschlussklemmen Käfigzugfederklemmen
