|DC output||12 - 15Vdc|
|8 - 6.4A|
|Input||AC 380 - 480V (-15%/+20%)|
|Dimensions (WxHxD)||40 x 124 x 117mm|
|AC Input voltage||AC 380 - 480V (-15%/+20%)|
|Input inrush current limitation||active|
|Input inrush current||4A / 4A|
|External input fuse recommendation||B-6A / C-3A|
|Adjustment range||12 - 15V|
|Output current range||8 - 6.4A|
|Output current||6.4A at 15V|
|8A at 12V|
|Derating||2.5W/°C for >+60°C|
|Ripple and noise voltage max.||100mVpp|
|Dimensions (WxHxD)||40mm x 124mm x 117mm|
|Weight per unit (excl. packaging)||500g|
|Mounting method||DIN rail|
|Operating temp. range||-25°C to 70°C|
|Connection method||Screw terminals|
|Power losses, typ.||16.4W|
|MTBF SN 29500 @ 40°C (h)||983000h|
