TP960.241
New
DIN rail power supplies for 3-phase system
24 V, 48 A AC-OK, DC-OK, parallel use
Datasheet
24 V, 48 A AC-OK, DC-OK, parallel use
| DC output | 24 - 28 Vdc |
|---|---|
| 48 - 41.1 A | |
| 960 W | |
| Input | AC 380 - 500 V (-15 %/+10 %) |
| Dimensions (WxHxD) | 79 x 124 x 136 mm |
| Weight | 1100 g |
Input data
| AC Input voltage | AC 380 - 500 V (-15 %/+10 %) |
|---|---|
| Power factor | 0.91 |
| Input inrush current limitation | active |
| External input fuse recommendation | B-16 A / C-16 A |
Output data
| Nominal voltage | 24 Vdc |
|---|---|
| Adjustment range | 24 - 28 V |
| Output current range | 48 - 41.1 A |
| Output current | 41.1 A at 28 V |
| 48 A at 24 V | |
| Output power | 960 W |
| Power reserves | 200 % BonusPower |
| Derating | 12.8 W/°C for +45 to +60 °C |
| 8 W/°C for +60 to +70 °C | |
| Ripple and noise voltage max. | 50 mVpp |
Overview
| Dimensions (WxHxD) | 79 mm x 124 mm x 136 mm |
|---|---|
| Weight per unit (excl. packaging) | 1100 g |
| Mounting method | DIN rail |
| Housing material | Metal and plastic |
| Operating temp. range | -40 °C to 70 °C |
| Connection method | Spring clamps |
| Efficiency, typ. | 97 % |
| Power losses, typ. | 28 W |
| MTBF SN 29500 @ 40 °C (h) | 342 000 h |
| DC-OK signal | yes |
