DIN rail power supplies for 1-phase systemDatasheet
36 V, 13.3 A
36 V, 13.3 A
|DC output||36 - 42 Vdc|
|13.3 - 11.4 A|
|Input||AC 100 - 240 V (-15 %/+10 %)|
|Dimensions (WxHxD)||65 x 124 x 127 mm|
|AC Input voltage||AC 100 - 240 V (-15 %/+10 %)|
|Input inrush current limitation||active|
|Input inrush current||9 A / 7 A|
|External input fuse recommendation||B-10 A / C-10 A|
|Nominal voltage||36 Vdc|
|Adjustment range||36 - 42 V|
|Output current range||13.3 - 11.4 A|
|Output current||11.4 A at 42 V|
|13.3 A at 36 V|
|Output power||480 W|
|Power reserves||20 % Power Boost|
|Derating||12 W/°C for >+60 °C|
|Ripple and noise voltage max.||100 mVpp|
|Dimensions (WxHxD)||65 mm x 124 mm x 127 mm|
|Weight per unit (excl. packaging)||1000 g|
|Mounting method||DIN rail|
|Operating temp. range||-25 °C to 70 °C|
|Connection method||Screw terminals|
|Efficiency, typ.||94.3 %|
|Power losses, typ.||29.0 W|
|MTBF SN 29500 @ 40 °C (h)||537000 h|
